‘-86℃ Digital display Ultra low temperature upright freezer for Lab/Hospital YR05107

Manufacturer: Kalstein

Description

The YR05107 Ultra Low Temperature Upright Freezer is expertly engineered for the precision storage of sensitive biological specimens at ultra-low temperatures. With a sizable capacity of 188 liters, this freezer is essential for blood banks, hospitals, research laboratories, and chemical plant facilities. It offers an extensive temperature range from -40°C to -86°C, governed by a concise microprocessor. Featuring a sophisticated refrigeration system utilizing mixed refrigerants, the YR05107 ensures dependable cooling while high-efficiency PURF insulation guards internal temperatures. This device, demanding only 660W of nominal power and operating at 4.3A, is a prudent choice for any institution in need of stringent control over invaluable biological samples.

Market Price

The YR05107 Freezer is competitively priced within a market range of approximately $4700 to $5400 USD. This budget-friendly bracket reflects the freezer’s exceptional capacity, superior temperature precision, energy efficiency, and robust safety measures. For a facility aiming to safeguard critical biological items, this model stands out as a stellar investment.

Frequently Asked Questions

  • Does this freezer maintain temperature during a power outage? Yes, the YR05107 features a backup system to sustain alarms and temperature readings for up to 72 hours without external power.
  • How is the temperature controlled in this freezer? The freezer employs a digital display microprocessor for exact temperature control within a -40°C to -86°C range, with clear alerts for any deviations.
  • Is this freezer suitable for transporting biological products? Primarily intended for stationary use, the YR05107 can be transported if properly powered and secured.

Advantages and Disadvantages

Advantages:

  • Designed for energy efficiency, offering significant cooling with lower energy use.
  • Ensures precise temperature control via a microprocessor and digital interface.
  • Equipped with advanced safety systems such as temperature and power alerts.
  • Convenient stainless steel structure and a wheel system for easy manipulation.

Disadvantages:

  • The high price point may pose a challenge for budget-restricted organizations.
  • Requires regular maintenance to guarantee optimal system and alarm performance.

Product Use in the Field

The YR05107 Freezer is indispensable in blood banks, medical laboratories, hospitals, and biotech centers where secure, ultra-low temperature storage is crucial. Storing large volumes of blood, plasma, vaccines, and other biologics benefits precision medicine and clinical studies. Its efficiency and durability make it suited for industries demanding long-term critical sample storage.

Recommendations

For prolonged efficiency and full functionality of the YR05107 Freezer, routine preventive maintenance is recommended. Regular testing of alarms and internal temperature, routine condenser cleaning, and ensuring that doors are sealed to prevent temperature loss are key practices. During transport of biological contents, ensure that the freezer is adequately powered and stabilized. For those seeking further specification details and pricing, consider generating an automatic quote via the Kalstein Plus platform.

Features

  • Ultra-low temperature range (-40°C to -86°C).
  • Digital display with microprocessor temperature control.
  • Stainless steel shelves for durability.
  • Backup system for 72-hour operation during power outages.
  • Energy-efficient, environmentally-friendly refrigerant use.

Technical Specifications

Model YR05107
Specifications
Shelf/drawer QTY Stainless steel shelf/2
Cooling Direct cooling
Defrost Manual
Refrigerant Mixed-gas
Power Consumption(kWh/24h) 8.2
Noise(db) 52
Ambient temperature(℃) 10~32℃
Temperature range(℃) -40~-86℃
Cooling system
Compressor brand/QTY CUBIGEL/1
Sensor PTC
Temperature controller Microprocessor
Display Digital display
Power
Voltage/frequency(V/Hz) 220/50Hz
Power(W) 660W
Current(A) 4.3A
Material
Inside material Stainless steel
Outside material Color sprayed steel
Insulation PURF
Size
Capacity(L/cu.ft) 188/6.63
NT./GT.(kg) 174/224
Exterior size(W*D*H)(mm) 850*930*1595
Interior size(W*D*H)(mm) 465*465*830
Package size(W*D*H)(mm) 880*910*1820
CBM 1.46
20GP/40GP/40HQ 12/26/26
Frozen Racks
Racks 9(4X3)
Boxes (2 Inches) 108
Samples(2ml) 10800
Alarm
High/low temperature Y
Power failure Y
Abnormal voltage Y
Sensor error Y
Filter screen check Y
Thermostat failure Y
Low battery Y
Condenser clean Y
High ambient temperature Y
Door ajar Y
Power failure backup system(alarm) 72h
Accessories
Castor Y
Inside door 3
Test hole QTY/diameter 1/25MM
USB port Y
Chart recorder /
Data logger Optional
Remote alarm port Y
Optional
CO2 back up system Optional
LN2 back up system Optional
Other Certification ISO.CE

Additional information

Weight 252,00 kg
Dimensions 91,5 × 92,8 × 1181,8820 cm
